3522.5-0000010 РЭ
76
Electrical connection of equipment harnesses to the swithing unit is presented in
figure 2.18.5.
а) connection of electrical harnesses to БКА-7.3722
b) connection of electrical harnesses to БК-1
Figure 2.18.5 – Diagram of equipment harnesses connection to the switching unit
harness
Harness of roof
starter coil
harness
harness
Orange wire to starter coil
