K-FRAME — User Manual 443
Image Store Build Edit
Image Store Record Modes
Normal Record Mode
Record a movie continuously until it is stopped or the Image Store cache is
full.
Timed Record Mode
Record a movie of a set duration.
Loop Record Mode
Record a video segment of a set duration (MM:SS.FF) from the last seconds
of a continuously streaming video. In Loop record mode, the last frame of
the buffer is displayed in output.
When recording in Loop mode, Image Store buffers video from the cur-
rently recording frame, back to the first frame of the defined duration; pre-
viously recorded frames are discarded as new ones are recorded.
When recording is stopped, the buffered video is available as an Image
Store movie.
Figure 250. Image Store Loop Record Mode Definition
Delay Line Record Mode
Record a video segment of a set duration (MM:SS.FF) from the last seconds
of a continuously streaming video with a delay. In Delay Line record mode,
the first frame of the continuously recording video in buffer is displayed in
output, therefore the recorded frames up to the end of the recording are
delayed.
Note When recording is first started in Delay Line record mode, after one second
the first frame will freeze until the remaining frames of the defined duration
have been recorded into the buffer.
When recording in Delay Line mode, Image Store buffers video of a set
duration. The buffered video is captured from the currently recording
Streaming Source Video
First Frame
Last Frame
Frame displayed
in output
Recorded Segment
Configurable Duration
