Belimo ECON-ZIP-BASE User Manual

11
0
6/16 - Subject to change. © Belimo Aircontrols
(
USA
)
, Inc
.
Installation
Dimensions in Inches [mm]
A
void mounting in areas where acid
f
umes or other deteriorating vapors
can attack the metal parts, or in areas where escaping gas or other
explosive vapors are present.
Mount the sensor in a position that will allow for proper clearance for
installation, servicing, wiring, and removal.
Usin
g
the dimensions as a reference, mount the 10K Sensor on the outside
of the dampers to measure outside temperature, or inside the return air
duct to measure the return temperature. If mounted outside, the sensor
must be placed within hood behind the outdoor air fi lter. It needs to be
protected from direct exposure to water
(
snow/rain
)
and direct exposure to
sunli
g
ht
(
UV radiation
)
.
Secure the sensor with #8 self-tapping screws (included in kit) using a size
16 or 18
d
r
ill.
Wiring Diagram
ZIP Economizer Terminal inputs
SAT (+/-)
O
AT (+/-
)
R
AT (+/-
)
E
CON-ZIP-10K
ECO
N-ZIP-1
0K
ZIP Economizer™ Tem
p
erature
S
enso
r
Technical Data
T
emperature output si
g
nal NT
C
10k
O
hm, T
y
pe II
C
onnector
s
1/4"
f
emale spade insulated connectors,
3
f
t. cabl
e
Accurac
y
± 0.36°F,
(
± 0.2°C
)
S
tabilit
y
drift less than 0.036°F/yr [0.02°
C
/yr
]
M
ater
i
a
l
etched Teflon, plenum-rated & FEP
j
ackete
d
cable;
g
alvanized t-bracket
A
m
bi
ent temperature range -67°F to +176°F (-55°
C
to +80°
C
)
