Actuators with damper rotation for square form-fit spindles (8 mm), see documentation 2.A12/LMC-F-1/E
Damper actuators, Open/Close
LMC24 4
LMC24-S 4
LMC230 5
LMC230-S 5
Mounting instructions 6
Adjusting the auxiliary switch 7
Damper actuator, modulating
LMC24-SR 8
Mounting instructions 9
Control and monitoring functions 10
Contents
Nominal voltage AC 24 V •• •
DC 24 V •• •
AC 230 V ••
Running time 25...35 s •••••
Control Open/Close Single-wire ••••
2-wire ••
Modulating DC 0...10 V •
Direction of rotation reversible (right/left) •••••
Manual operation by pushbutton •••••
Auxiliary switch potential-free ••
Mechanical angle of rotation limiting ••••
Electronic angle of rotation limiting •
Continuous position feedback •
Damper rotation with universal spindle clamp •••••
Selection table
LMC24-SR
LMC230-S
LMC230
LMC24-S
LMC24
Torque 2 Nm
BC
