NM24A-V-ST
Ready-to-connect operating unit
24 / 28 Product information S4-VRP-M VAV • en • v2.0 • 11.2006 • Subject to changes www.belimo.eu
Accessories
Description Data sheet
Electrical accessories
Auxiliary switch S..A.. T2 - S..A..
Feedback potentiometer P..A.. T2 - P..A..
Mechanical accessories
Spindle extension AV6-20 T2 - Z-NM..A..
Product features
Mode of operation
The actuator is controlled with a Belimo VRP-M controller and travels to the position
defined by the control signal.
Simple direct mounting
Simple direct mounting on the damper spindle with a universal spindle clamp, supplied with an
anti-rotation strap to prevent the actuator from rotating.
Manual override
Manual override with self-resetting pushbutton possible (the gear is disengaged for as long as
the button is pressed).
Adjustable angle of rotation
Adjustable angle of rotation with mechanical end stops.
Adaptation
Angle-of-rotation sensing and adaptation of the control range. Triggered by pressing a button on
the actuator, with LEDs for status display.
High functional reliability
The actuator is overload-proof, requires no limit switches and automatically stops when the end
stop is reached.
Electrical installation
The ready-to-connect operating unit is connected to the VRP-M-controller.
Safety notes
(continued)
• The device contains electrical and electronic components and is not allowed to be disposed
of as household refuse. The local and currently valid regulations and requirements must be
observed.
