INTRODUCTION
Product Specifications
Computer Interface: IEEE 802.3/802.3u
Operating Temperature: 32–131 degrees F (0–40 degrees C)
Storage Temperature: -13–155 degrees F (-20–65 degrees C)
Humidity: Max. 5%–95% (non-condensing)
*The standard transmission rate—500Mbps—
is the physical data rate.
Actual data throughput will be lower.
Power LED
Solid Green – Adapter running normally
Blinking Green
– Adapter is resetting
– Adapter is in the process of password synchronization
Off – Adapter powered off
Ethernet Link LED
Solid Green – 10/100/1000Mbps port linked
Blinking Green – Data transmitting or receiving
Off – No Ethernet link
Data LED
Color Green – Link rate excellent: greater than 80Mbps
Color Amber – Link rate between 10 and 80Mbps
Color Red – Link rate less than 10Mbps
Off
– Encryption setup failure
– Adapter not connected to powerline network
