5
Overview
Installation of the Powerline AV500 Network Adapter takes only
seconds and does not require setting up long wires throughout the
house. Simply plug the units directly into any available wall outlet and
connect to any device with an Ethernet port. Users have the option to
randomly change the security password for their powerline network.
Hardware Setup
1. Plug your network cable into the device’s
RJ45 network adapter port.
2. Plug the other end of your network cable into the
RJ45 port located at the back of the Adapter.
3. Plug the power cable or wall adapter into the power connector
at the back of the Adapter.
4. Insert the power plug of your power cable or wall
adapter directly into a power outlet in the wall.
NOTE: Do not plug the device into a UPS or power strip with
surge protection as they may filter the powerline signal.
5. Repeat this process for the second Adapter.
INSTALLING AND SETTING UP THE ADAPTERS
