To Next PageTo Next PageWhat to do if the Bell System BSX lock operates from the test button but not from a phone?
If the lock operates from the test button but not from a phone, it could be due to: * A faulty connection to phone Z; inspect and fix the connection. * A stuck lock button; check and free the lock button if it's stuck.
Why does the Bell System BSX phone reset when called (BS-LX)?
If the phone resets when called (BS-LX), inspect the cable length and connections, as it could be due to a cable that is too long or a poor connection.
Why doesn't the mute LED come on in my Bell System BSX?
If the mute LED doesn't come on, it could be because: * Phones with a ring LED need 12V on V; ensure 12V is present. * Mute is disabled in the settings; enable mute in the settings.
Why does the Bell System Intercom System phone keep ringing quietly?
If the phone keeps ringing quietly, it could be due to: * A broken T core between the phone and panel; replace the T core. * A faulty 61 Speech unit; replace the 61 Speech unit.
Why is the Bell System BSX Intercom System lock open/close operation reversed?
If the lock's open/close operation is reversed, verify that the configuration of SW1-8 matches the lock type.
Why is there other noise or interference audible at the Bell System BSX entrance panel?
If you're experiencing noise or interference at the entrance panel, it could be due to: * The use of alarm cable; avoid using alarm cable. * Adjacent data cables; keep data cables separated.
Why is the Bell System Intercom System maglock not holding strongly?
If the maglock does not hold strongly, it may be due to a voltage drop caused by an insufficient cable diameter. Use a cable with a larger diameter.
What to do if the Bell System Intercom System phone does not ring when called?
If the phone doesn't ring when called, check the following: * Ensure the phone is not muted; unmute the phone. * Ensure the phone is on the hook; place the phone on the hook. * Confirm the presence of the Ring volume PCB jumper.
What to do if the Bell System BSX lock does not operate but the LED flashes?
If the lock doesn't operate but the LED flashes, consider these potential causes: * Faulty or incorrect connections to the Lock (open-circuit); check the connections. * Voltage drop due to cable being too thin; use a thicker cable. * Lock release jammed due to overtight fitting; adjust the lock fitting.
Why is there a loud howling noise at the Bell System Intercom System entrance panel?
A loud howling noise at the entrance panel, also known as acoustic feedback, can occur for several reasons: * The volume controls on Model 61 are set too high; reduce the volume. * There is a short-circuit from “R” to “T”; check for short circuits. * Alarm cable is being used, or “R&H” or “R&O” are not in a twisted pair; use twisted pairs for connections. * “R” is twisted with “T” instead of “H” or “O”; reconfigure the wiring to ensure proper twisting.
Key features of the BSX Isolated Audio Entry System, including duplex speech, isolation, and vandal resistance.
Procedure for visitors to initiate a call from the entrance panel to a resident's phone.
Details on how the system ensures private conversations between callers and residents.
Explains the Ringer Mute feature for phones to avoid nuisance calls.
Describes the Door Status Indication feature for monitoring the entrance door.
Information on the optional Trades button for independent access and time clock control.
How the system handles calls when a second entrance is in use.
Details on the optional Egress button for exiting the building.
Lists all necessary components for different BSX system configurations.
Details on Vandal Resistant and Laser-Cut Vandal Resistant entrance panels.
Description of the lockable steel cabinet housing control PCBs, power supply, and time-clock.
Overview of standard (801, 801S) and advanced (BS-LX) phone models.
Explanation of Fail-Safe and Fail-Secure lock release types and requirements.
Details on the Egress button and DDA panel features.
Specifications for phone and door panel cable types and maximum lengths.
Details on power supply units (Cab3, Cab5) and battery backup capabilities.
Important safety checks, general guidelines, and initial steps for installation.
Procedures for installing the control unit box and mounting the entrance panel.
Wiring and configuration for electric door releases, connections to phones, and door monitoring.
Details on installing the exit button and configuring tone outputs.
Configuration of the BSX2 controller via DIP switches for various system functions.
Setting up BS-LX and 801xx phone models, including ringer and mute functions.
Operation and programming of the TS2000-BST Time Clock for the Trades facility.
Safety precautions to be taken before and during system testing and commissioning.
Step-by-step guide for performing a basic functional test of the system.
How to adjust the volume controls on the Model 61 Speech Unit for optimal clarity.
Procedure for testing the system with mains power on and off to verify battery backup.
Identifies common wiring faults and connection issues encountered during installation.
Verifying controller PCB DIP switch settings before troubleshooting.
Diagnosing and resolving problems related to the electric door lock release operation.
Steps to diagnose and fix issues with establishing calls, ringing, and button operation.
Resolving issues with one-way speech, volume, or noise during conversations.
Procedures for testing individual phones and speech units for correct operation.
Technical specifications for the BSX2 controller PCB, including size and power.
Specifications for 801, 801P, 801S, 801PS, and BS-LX audio phones.
Technical details for Cab 3 and Cab5 battery-backed power supplies.
Diagram showing the layout and terminal connections on the BSX2 controller PCB.
Diagram illustrating how to connect BS-LX and 801 phones to the controller.
Diagrams for wiring push buttons, trades, time clock, and door equipment.
Diagrams for connecting Bell 200, ACT FOB, and Paxton FOB access systems.
Wiring diagrams for connecting other equipment to BSX drives locks.
Safety requirements for connecting the 240VAC mains supply by qualified personnel.
Guidelines for installing the BSX2 control cabinet in a protected environment.
Ensuring proper earthing and safe handling of the system battery.
General| Brand | Bell System |
|---|---|
| Model | BSX |
| Category | Intercom System |
| Language | English |
