MACHINE INFORMATION
MACHINE SPECIFICATIONS
Bin raise time 11 seconds
Binloweringtime 6seconds
B50E
Bin raise time 11.5 seconds
Binloweringtime 6seconds
B60E
Bin raise time 13.5 seconds
Bin lowering time 13.5 seconds
Mass
NOTE
Machine mass may increase depending on
specifications and added options.
B35E 6X6
Total mass, empty 30 379 kg
Total mass, fully laden 63 879 kg
B40E 6X6
Total mass, empty 31 787 kg
Total mass, fully laden 70 787 kg
B45E 6X6
Total mass, empty 31 877 kg
Total mass, fully laden 72 877 kg
B50E 6X6
Total mass, empty 35 299 kg
Total mass, fully laden 80 699 kg
B60E 4X4
Total mass, empty 42 476 kg
Total mass, fully laden 97 476 kg
Hydraulic System
Type (B35E, B40E, B45E,
B50E & B60E)
Load sensing
Pump - Main Hydraulic System
Model Rexroth A10VO72
Pump - Emergency Steering System
Model Parker P1028 or Rexroth
A10VO28
Pneumatic System
B35E, B40E, B45E, B50E & B60E
Reservoir capacity 20 litres (5.28 USGAL)
Noise Emission
The Guaranteed External Sound Power Level, as measured
accordingtoISO6395
Standard
B35E, B40E, B45E, B50E &
B60E
Lwa 106 dB
Blu@dvantage
B35E, B40E, B45E, B50E &
B60E
Lwa 106 dB
The Guaranteed Internal Sound Pressure Level at operator's
position, as measured according to ISO 6396
Standard
B35E, B40E, B45E, B50E &
B60E
LpA 75 dB
Blu@dvantage
B35E, B40E, B45E, B50E &
B60E
LpA 75 dB
Service Capacities
See the section under Lubricant Specifications for details of
fluids to be used, in the different components.
Engine (OM 470 LA ) B35E
Engine oil (in oil pan) 31 litres (8.19 USGAL)
Engine oil (Service fill includ-
ing filter)
34 litres (8.98 USGAL)
Engine (OM 471 LA) B40E & B45E
Engine oil (in oil pan) 36 litres (9.51 USGAL)
Engine oil (Service fill includ-
ing filter)
39 litres (10.3 USGAL)
Engine (OM 473 LA ) B50E & B60E
Engine oil (in oil pan) 39 litres (10.3 USGAL)
Engine oil (Service fill includ-
ing filter)
42 litres (11.1 USGAL)
Engine Coolant
Engine coolant (initial and
service fills) B35E
58 litres (15.32 USGAL)
Engine coolant (initial and
service fills) B40E & B45E
65 litres (17.17 USGAL)
81,392 Lbs
171,145 Lbs
85,164 Lbs
189,653 Lbs
85,405 Lbs
195,253 Lbs
94,573 Lbs
216,209 Lbs
113,802 Lbs
261,159 Lbs
