MACHINE INFORMATION
MACHINE SPECIFICATIONS
Engine coolant (initial and
service fills) B50E & B60E
66 litres (17.44 USGAL)
Transmission (Allison 4500 ORS) - B35E
Transmission fluid (initial fill) 47 litres (12.42 USGAL)
Transmission fluid (service
fill)
45 litres (11.89 USGAL)
Transmission (Allison 4700 & 4800 ORS) - B40E, B45E,
B50E & B60E
Transmission fluid (initial fill) 57 litres (15.06 USGAL)
Transmission fluid (service
fill)
48 litres (12.68 USGAL)
Transfer case (VGR18000, VGR18050) B35E, B40E, B45E,
B50E
Transfer Case (initial and
service fills)
7.4 litres (1.95 USGAL)
Transfer case (Kessler W3430) B60E
Transfer Case (initial and
service fills)
13.7 litres (3.62 USGAL)
Hydraulic Reservoir
Hydraulic reservoir (initial fill) 350 litres (92.46 USGAL)
Hydraulic reservoir (service
fill)
175 litres ( 46.23 USGAL)
Axles
B35E, B40E & B45E
Axle oil per axle 65 litres ( 17.17 USGAL)
Axle oil (service fill) 65 litres ( 17.17 USGAL)
Final drive oil (per final drive) 7 litres ( 1.85 USGAL)
B50E
Axle oil per axle 77 litres (20.34 USGAL)
Axle oil (service fill) 77 litres (20.34 USGAL)
Final drive oil (per final drive) 7 litres (1.85 USGAL)
B60E
Axle oil per front axle 77 litres ( 20.34 USGAL)
Axle oil per front axle (service
fill)
77 litres ( 20.34 USGAL)
Axle oil per rear axle 100 litres ( 26.42 USGAL)
Axle oil per rear axle (service
fill)
100 litres ( 26.42 USGAL)
Final drive oil (per final drive) 7 litres ( 1.85 USGAL)
Cab tilt system
Cab tilt system 0.80 litres (0.2 USGAL)
Windscreen washer bottle
Windscreen washer bottle 6 litres (1.59 USGAL)
Fuel tank (Stage 3A)
B35E, B40E & B45E 533 litres (140.8 USGAL)
B50E 559 litres (147.67 USGAL)
B60E 588 litres (155.33 USGAL)
Fuel tank (SCR - Blu@vantage)
B35E, B40E & B45E 352 litres (92.99 USGAL)
B50E 366 litres (96.69 USGAL)
B60E 395 litres (104.35 USGAL)
AdBlue® / DEF Tank
AdBlue® / DEF Tank 40 litres (10.57 USGAL)
Lubricant Specifications
Engine Oil Specification
Approved MB 228.5
Approved - Essential when
using diesel fuel that has a
Sulphur content of < that 50
ppm
MB 228.51
Operating Ambient Temp. Viscosity
-20°C (-4°F) to 50°C (122°F) SAE 10W-40
Bell Lubricant – BN005545
Engine Coolant Specification
Approved MB326.5 (Premixed Coolant)
50/50
Bell Lubricant - BN033240
Approved MB325.5 (Neat Concentrate)
Bell Lubricant - BN041738
Transmission Oil Specification
Approved Allison TES-295
Operating Ambient Temp. Viscosity
-20°C (-4°F) to 50°C (122°F) SAE 70W-80
Bell Lubricant – BN005548
Transfer case Oil Specification
Approved Allison TES-295
Operating Ambient Temp. Viscosity
-20°C (-4°F) to 50°C (122°F) SAE 70W-80
Bell Lubricant – BN005548
Hydraulic Oil Specification
6
6
E
#
A
D
T
'
S
&
H
A
U
L
E
R
S
O
P
E
R
A
T
O
R
'
S
M
A
N
U
A
L
