MACHINE INFORMATION
MACHINE SPECIFICATIONS
6th Forward 41 km/h (25.5 mph)
7th Forward 47 km/hr (29.2 mph)
Reverse 6 km/hr (3.7 mph)
Transfer Case
B35E ADT Bell VGR 18000
B40E ADT Bell VGR 18050
B45E ADT Bell VGR 18050
B50E ADT Bell VGR 18050
B60E ADT Kessler W3430
Steering System
Type Double-acting cylinders, with
ground-driven emergency
steering pump.
B35E, B40E & B45
Turns (lock to Lock)
5
Turns (Centre to Lock) 2.5
B50E & B60E
Turns (lock to Lock) 4.9
Turns (Centre to Lock) 2.4
Brakes
Service brakes
Type Dual circuit, full hydraulic ac-
tuation wet disc brakes on
front and middle axles. (Ap-
plicable to the front, middle
and rear axles on B50E)
Park Brake
Model DXP195
Type Spring applied, air released,
drive-line mounted disc
Auxiliary Brake
Type Automatic engine valve
brake
Automatic retardation
through electronic activation
of wet brake system
Electrical System
CDU (Colour Display Unit) 10" LCD
Voltage 24 VDC
Battery type 2 x 12 V, AGM
Battery capacity Cold Crank Amps (CCA)
(BCI 0°F): 900 amps, 75 Ah
each
Starter motor capacity 9 kW
Alternator voltage rating 28 V
Alternator amperage rating 100 A
Power ratings (bulbs)
Headlight 24 V 70/75 W
Front Park light 24 V 4 W
Front Indicator light 24 V 21 W
Number Plate light 24 V 5 W
Stop/Tail light 24 V diode light unit
Rear Indicator light 24 V diode light unit
Reverse light 24 V 75 W
Interior light 24 V 10W
Rear View Camera (Option on
ADTs Only)
Specifications
Image Interline transfer type CCD
Picture Elements NTSC: 270,000 Pixels PAL:
320,000 pixels
Image Size 1/3 Inch
Lens Focal Length 2,75 mm
Synchronisation Internal
Horizontal resolution 330TV Lines
Required illumination 0.1 Lux minimum
Signal to noise ratio Min. 47 dB (at AGC off)
Power Supply 12 VDC
Power Consumption >2.4 W
Current Consumption >300 mA
Operating Temperature -30˚C to +50˚C (-22˚F to
+122˚F)
Weight 0.4 Kg
Dimensions 69 (W) X 43 (H) X 61 (D) mm
/ 2.7 (W) X 1.7 (H) X 2.4 (D)
inch
