MACHINE INFORMATION
MACHINE SPECIFICATIONS
Illumination Distance 5 Meters
Vibration Rating 20 G
Shock Rating 100 G
Frame And Body
Cab
Type FOPS (ISO 3449) / ROPS
(ISO 3471)
Principal Chassis Components
Type Front Chassis, Rear Chassis,
Male Oscillation Joint.
Materials
Type Structural steel and high
strength steel
Front Chassis Construction
Type I-section beams and boxed
transverse members
Rear Chassis Construction
Type Dual box-type longitudinal
beams, two boxed transverse
members and one transverse
tubular member
Bin
Type Ribless structure manufac-
tured from high tensile wear
and impact resistant, alloy
steels.
Retrieval Points (in conformance with ISO 10532) B35E,
B40E, B45E & B50E
Type Two points on the front chas-
sis and two points on rear
chassis.
Retrieval Points (in conformance with ISO 10532) B60E
Type Two points on the front chas-
sis and two points on rear
axle housing.
Tie-down Points (in conformance with ISO/DIS 15818)
B35E, B40E, B45E & B50E
Type Two points on the front chas-
sis, two points on the front of
the rear chassis and two
points at the rear of the rear
chassis.
Tie-down Points (in conformance with ISO/DIS 15818)
B60E
Type Two points on the front chas-
sis, two points on the front of
the rear chassis and two
points on the rear axle
housing.
Lifting Points (in conformance with ISO/DIS 15818)
Type Two points on front chassis
and two points on bin.
B35E
Rated payload 33 500 kg (73 855 lb.)
Capacity struck 16 m³ (20.9 yd.³)
Capacity heaped (SAE 2:1) 20.5 m³ (26.8 yd.³)
Capacity heaped (SAE 1:1) 24.5 m³ (32 yd.³)
B40E
Rated payload 39 000 kg (85 980 lb.)
Capacity struck 19 m³ (24.9 yd.³)
Capacity heaped (SAE 2:1) 24 m³ (31.4 yd.³)
Capacity heaped (SAE 1:1) 28.5 m³ (37.3 yd.³)
B45E
Rated payload 41 000 kg (90 390 lb)
Capacity struck 19.5 m³ (25.5 yd.³)
Capacity heaped (SAE 2:1) 25 m³ (32.7 yd.³)
Capacity heaped (SAE 1:1) 29.5 m³ (38.6 yd.³)
B50E
Rated payload 45 400 kg (100 090 lb)
Capacity struck 21.5 m³ (28.1 yd.³)
Capacity heaped (SAE 2:1) 27.5 m³ (36 yd.³)
Capacity heaped (SAE 1:1) 33 m³ (43.2 yd.³)
B60E
Rated payload 54 500 kg (120 152 lb)
Capacity struck 27 m³ (35.3 yd.³)
Capacity heaped (SAE 2:1) 35 m³ (45.8 yd.³)
Capacity heaped (SAE 2:1) 42 m³ (54.9 yd.³)
Tip Cylinders (B35E, B40E, B45E & B50E)
Tip cylinders 2 x single stage, double
acting
Tipping angle max. Can be
limited to any lower angle,
programmable on CDU.
70°
Tip Cylinders (B60E)
Tip cylinders 2 X two stage, double acting
telescopic
Tipping angle max. Can be
limited to any lower angle,
programmable on CDU.
55°
B35E, B40E & B45E
6
4
E
#
A
D
T
'
S
&
H
A
U
L
E
R
S
O
P
E
R
A
T
O
R
'
S
M
A
N
U
A
L
