SERVICE AND CHECKS
10 HOURLY OR DAILY SERVICE AND CHECKS
5. Select Diagnostics.
6. Scroll down to Hydraulics.
7. Under the Hydraulics tab, oil levels for both
WDB and Hydraulic tanks can be checked. It
will be indicated as “FULL” which then indicates
thecorrectlevel,or“OVERFULL”thisthenre-
quires oil to be drained from the tank, or
“UNDER FULL” which indicates oil needs to be
topped up into the tank.
Tailgate Checks
When any maintenance is to be carried out with the
engine running the machine must still remain in the
service position as described in Part 1, Chapter 1
(Service Instructions) and all procedures in Part 1,
Chapter 3 (Procedures Before Starting).
Check Tailgate And Leaf Springs
(Option)
Extreme caution should be taken when removing leaf
springs as they are under tension. serious injury could
result if proper safety measures are not taken into
account.
Do not use chemicals to remove paint from the leaf
springss as this can reduce the ductility and load
bearing capacity of the leaf springs.
There is a risk that the ADTs will “ tip” over if the
springs fails and the tailgate does not open while
tipping.
No Grinding, Welding / Cutting or repairs to be attempted
on the spring while on the machine as it may be under
load / tension.
Note that the leaf springs are safety critical
components
Report to service personnel if any damage is noted.
1. Check that the tailgate system is free from
blockages (may also be caused by external
source), and damages, which can affect the
proper operation of the system.
2. Clean out any blockage on the bin especially
the area that the tailgate rests on. This will en-
sure that the tailgate closes fully and that no un-
due stress is put onto the leaf springs.
3. Do not use chemicals to remove paint from the
leaf springs as this can reduce the ductility and
load bearing capacity of the leaf springs.
