ASSEMBLING THE FRY BASKET HANDLE
1. To attach the handle to the fry basket,
hold handle inside fry basket as shown.
Gently squeeze the arms of the handle
so they fit into the eyelets on the fry basket.
See Figure 2.
2. Unfold the handle toward
the back of the fry basket. Push handle
against back of the fry basket
until it locks into place. See Figure 3.
BEFORE USING FOR THE FIRST TIME
1. Remove all packing material and labels from
the inside and outside of the Deep Fryer.
Check that there is no packaging
underneath and around the oil tank
and control panel/heater assembly.
2. Set the lid and the fry basket aside.
3. Grasp the sides of the control panel/
heater assembly firmly and lift up
and off the Deep Fryer body. (See Figure 1.)
Carefully set control panel/
heater assembly aside.
4. Lift the oil tank up and out of the deep fryer
body.
5. Wash lid, fry basket, and oil tank in hot,
soapy water. DO NOT IMMERSE THE
CONTROL PANEL/HEATER ASSEMBLY
IN WATER. Wipe control panel/heater
assembly and deep fryer body
with a damp cloth. Dry all parts thoroughly.
6. Insert oil tank into deep fryer body.
Be sure tank is centered and resting properly on top of the stainless steel body.
7. Attach the control panel/heater assembly.
Slide the 2 brackets located on the inside wall of the heater assembly down
into the 2 retaining slots on the back of the deep fryer body. Make sure the brackets
are fitted securely in the 2 slots.
IMPORTANT: The Deep Fryer will not operate if the heater assembly brackets
are not fully inserted and properly attached to the deep fryer body.
8. Fold the fryer basket handle over into the basket. (See Figure 3.) Place folded basket
into the oil tank to store.
9. Replace lid on top of oil tank. Store until ready to use.
Fig. 4
Brackets
Retaining
slots
Fig. 2 Fig. 3
Eyelets
6
