ELECTRICAL SAFETY
The wires in the power cable of this product are coloured in accordance with the
following code:
Blue = Neutral Brown = Live
If the markings on the terminals of your plug do not correspond to the colours of the
wires in the power cable, proceed as follows:
The wire which is coloured Blue must be connected to the terminal which is marked N
or coloured Black
The wire which is coloured Brown must be connected to the terminal which is marked
L or coloured Red.
DO NOT connect any wires to the Earth Terminal.
This symbol indicates that this 2-core appliance is Class II and does not require
an earth connection.
Ensure that the outer sheath of the cable
is rmly held by the clamp.
Plug should be BS1363/A approved.
Fit a 13 Amp fuse.
Blue
(Neutral)
Brown
(Live)
Fuse
