32
Bellfires
English
Instructions for use and installation instructions
SMART - BELL
RIGID CONCENTRIC FLUE Ø100 mm - Ø150 mm SYSTEM CONNECTION
POSSIBILITIES
Appliance: Distance X Distance Y
(min.-max.) (min.-max.)
Smart Bell 0 - 0,5 m 2,0 - 12,0 m -
REAR CONNECTION
2
4
28
10, 12, 13
14, 15
23
10, 11, 12, 13
17
16
18
23
24
24
16
X
Y
Figure 17: Vertical roof-mounted outlet without bend
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
Item descriptions:
see 3.4.2
Assemble
restriction plate
