Electric and gas connection location (see illustration below)
The electric connection can be found on the rear of the appliance.
The gas inlet can be found on the rear of the appliance, 56.5cm from the bottom of the appliance and
3.2cm from the left hand side of the appliance.
56.5cm
Electrical cable
entry point
Gas connector
point
3.2cm
to centre
CONNECT TO THE ELECTRICITY AND GAS SUPPLY
