25
5.3 REMOVING AND REASSEMBLING THE OVEN DOOR
Saddle
bracket
Recessed
form
1
2
3
To remove the oven door;
• Open the oven door(1).
• Open the saddle bracket up to end
position(2).
• Close the door till it almost reaches to
rd
the full closed position as shown in 3
figure and remove the door by pulling it
towards yourself.
NOTE: To re-assemble the door follow the
opposite
rules of removal.
Please pay attention that the
recessed forms should be positioned
properly on the hinge counterparts as
nd
shown on 2 figure.
!
