Whilst every care is taken to eliminate
burrs and raw edges from this product,
please take care when handling - we
recommend the use of protective
gloves during installation.
Moving the cooker
Please note that the (unpacked) weight
of this appliance is approximately
50kg. Take care if the appliance
needs to be lifted during installation -
always use an appropriate method of
lifting.
Do not attempt to move the cooker by
pulling on the doors or handles. Open
the door and grasp the frame of the
cooker, taking care that the door does
not shut on your fingers.
Take care to avoid damage to soft or
uneven floor coverings when moving
the appliance. Some cushioned vinyl
floor coverings may not be designed
to withstand sliding appliances without
marking or damage.
Clearances & dimensions
This appliance is type X regarding
installation requirements.
Appliance dimensions
All sizes are nominal, and some
variation is to be expected. The
‘depth’ of the cooker, as given below,
is to the front of the door and
excluding knobs and handles.
depth: 600mm
width: 600mm
height: 900 - 915mm
Clearances
No shelf or overhang or cooker hood
should be closer than a minimum of
650 mm, but check with cooker hood
manufacturer’s recommendations.
The cooker must have a side
clearance above hob level of 90mm
up to a height of 400mm.
Check that there are no projections
in the rear wall which will prevent
the lid (where fitted) being raised to
the vertical position.
This cooker may be fitted flush to
base units. However, for models with
side opening doors, we recommend a
side clearance of 60mm between the
cooker and any side wall.
23
