Whilst every care is taken to eliminate
burrs and raw edges from this product,
please take care when handling - we
recommend the use of protective
gloves during installation.
Moving the cooker
Please note that the weight of this
appliance is approximately 5 1 k g -
550mm (55cm) models. Take care if
the appliance needs to be lifted during
installation - always use an appropri-
ate method of lifting.
Do not attempt to move the cooker by
pulling on the doors or handles. Open
the door and grasp the frame of the
cooker, taking care that the door does
not shut on your fingers.
Take care to avoid damage to soft or
uneven floor coverings when moving
the appliance. Some cushioned vinyl
floor coverings may not be designed
to withstand sliding appliances without
marking or damage.
Clearances & dimensions
Appliance dimensions
All sizes are nominal - some variation
is to be expected. The ‘depth’ of the
cooker, as given below, is to the front
of the door & excluding knobs & handles.
depth: 600mm
width: 550mm
height - lid down: 900 - 915mm
height - lid raised: 1430 - 1445mm
Clearances
No shelf or overhang or cooker hood
should be closer than a minimum of
650mm, but check with cooker hood
manufacturer’s recommendations.
The cooker must have a side
clearance above hob level of 90mm
up to a height of 400mm.
To avoid damage to surround-
ing units a 10mm gap should
be left between the appliance
and the units. If this is not pos-
sible, a kit (part number 01
25552 00) may be ordered
from Customer Care which will
protect the units.
For models with side opening doors,
we recommend a side clearance of
60mm between the cooker and any
side wall to allow the door to be
opened fully.
19
Installation Instructions
