Benchmark AHB2 User Manual

AHB2 Instruction Manual Rev F Page 22
Crosstalk
 Better than -115 dB at 1 kHz
 Better than -92 dB at 20 kHz
Input Sensitivity
 Low-Gain = 22 dBu (9.8 Vrms)
 Mid-Gain = 14.2 dBu (4 Vrms)
 High-Gain = 8.2 dBu (2 Vrms)
 Use Mid-Gain or High-Gain settings for unbalanced inputs
 Unbalanced inputs require RCA to XLRM adapter cables
Input Impedance
 50 k Ohms, normal mode
 1 M Ohm, common mode
Input CMRR
 80 dB at 20 Hz, typical
 80 dB at 1 kHz, typical
 65 dB at 20 kHz, typical
Trigger I/O
 12 VDC 200 mA current-limited output to trigger turn-on of remote devices
 DC input for slaving to remote devices
 Input responds to 3.3 V logic and higher, VIL = 1.26 V, VIH = 2.7 V
 Absolute maximum input voltage = 30 Vdc
 Absolute minimum input voltage = -0.3 Vdc
 Input Impedance = 20 k Ohms
 Two 1/8" (3.5 mm) TRS jacks
 Tip = 12 Volt Trigger I/O, Ring = no connection, Sleeve = chassis ground
Damping Factor
 350 at 20 Hz, 8-Ohms
 254 at 1 kHz, 8-Ohms
 34 at 20 kHz, 8-Ohms
 7 at 200 kHz, 8-Ohms
Environmental
 0° C to 50° C (32° F to 122° F) Ambient Temperature
 Up to 80% Humidity - Non-condensing

Benchmark AHB2 Specifications

General

Signal to Noise Ratio	>130dB, A-weighted
Type	Stereo Power Amplifier
Power Output	100W into 8 Ohms, 190W into 4 Ohms
THD+N	<0.00013% at 1kHz, at 100W into 8 Ohms
Input Impedance	50 kOhms
Damping Factor	> 300
Frequency Response	0.1 Hz to 200 kHz (-3 dB)
