Plasma Cutting Guide
Cutting Charts
02
45 AMP: Mild Steel
45 Amp: Mild Steel
Material
Thickness
Cutting
Height
Pierce
Height
Dwell
Time
Cutting
Feed Rate
Cutting
(in.) (in.) (in.) (sec) (ipm) AMPs
0.0625 0.06 0.09 0 80 30-34
0.125 0.07 0.1 0 65 32-36
0.1875 0.08 0.11 0 50 35-40
0.25 0.09 0.12 0.25 35 42-45
0.375 0.09 0.12 0.5 25 45
45 Amp: Mild Steel - Fine Cut Consumables
Material
Thickness
Cutting
Height
Pierce
Height
Dwell
Time
Cutting
Feed Rate
Cutting
(in.) (in.) (in.) (sec) (ipm) AMPs
0.0625 0.05 0.09 0 80 30-34
0.125 0.06 0.1 0 65 32-36
0.1875 0.07 0.11 0 50 35-40
0.25 0.08 0.12 0.25 35 42-45
0.375 0.08 0.12 0.5 25 45
Re-do the Torch Mount when changing between ne cut consumables and regular
consumables.
