BENDIX A-18 TRAILER ABS - Top View

18
Gladhand
Gladhand
TEV or STEV
Spring Brake
Control
Res. Res.
Emergency
Brake
Chamber
Service
Brake
Chamber
ABS
ECU
3/4" Heavy Wall
Steel Pipe Nipple
Supply Line
Service (Control) Line
Front
ABS
Relay
Valve
3/8" O. D. Nylon Tubing
3/8" O. D. Nylon Tubing (Alt. 1/2" O. D.)
3/8" I. D. Hose
Key
Road Side
Top View
Road Side
Top View
ECU
Side
Wheel
Side
Power Cable
2S-1M Electrical Configuration (Top View)
J560 Connector
Trailer
Side
Warning
Light Side
Harness Side
ECU Side
Warning Lamp Connector
ABS Warning LampECU
Modulator
Valve
Diagnostic Port
Wheel Sensor Speed Sensor
Sensor B
Sensor A
Front
ABS
2S-1M Air System Configuration (Top View)
(Shown with
Extension)
Description Quantity
ECU/Relay Valve 1
Sensor/Diagnostics Cable 1
Valve/Power Cable 1
Sensors — 0.4m Cable 2
Sensor Friction Sleeve 2
Parts List
FIGURE 23 - Typical 2S-1M ABS Electrical and Air System
