BENDIX MC-30 TRAILER ABS CONTROLLER User Manual

22
FIGURE 17 - MC-30
™
CONTROLLER SYSTEM APPLICATIONS (2 OF 2)
4S/2M - SIDE CONTROL
Trailer Chassis Harness
NOTE:
For side control, MOD1 must
control the right side.
ABS Light
Left Front
WS Sensor
Right Front
WS Sensor
Right Rear
WS Sensor
Left Rear
WS Sensor
MC-30
MOD1
MOD2
Pigt ail Harness
AntiLock
Ignition
Power
Brake Light
Power
Ground
7-Pin
Connector
5-Pin
Connector
A Brake Light Power
B Ignition Power
C NC
D Warning Lamp
E Ground
C
E
B
A
D
ABS
Dual Axle Trailer
4S/2M - AXLE CONTROL
Trailer Chassis Harness
MOD2
NOTE:
For axle control, MOD1
must control the front axle.
ABS Light
5-Pin
Connector
A Brake Light Power
B Ignition Power
C NC
D Warning Lamp
E Ground
C
E
B
A
D
Ignition
Power
Brake Light
Power
Ground
7-Pin
Connector
ABS
Dual Spread Axle Trailer
Left Front
WS Sensor
Right Front
WS Sensor
Right Rear
WS Sensor
Left Rear
WS Sensor
MC-30
MOD1
Pigtail Harness
AntiLock
