RBJ Series of Rolling Bridge Jacks 9 P/N 5900004 — June 2018 — Rev. C2
Specifications
Model
RBJ4500 RBJ6000 RBJ7000
Lifting capacity 4,500 lbs / 2,041 kg 6,000 lbs / 2,721 kg 7,000 lbs / 3,175 kg
Minimum arm reach 42" / 1,069 mm 41.8" / 1,062 mm 41.8" / 1,062 mm
Maximum arm reach 57" / 1,449 mm 56.1" / 1,426 mm 56.1" / 1,426 mm
Maximum operating
hydraulic pressure
2,490 PSI 3,370 PSI 4,550 PSI
Shipping weight 305 lbs / 139 kg 305 lbs / 139 kg 305 lbs / 139 kg
Model
RBJ9000 RBJ15000
Lifting capacity 9,000 lbs / 4,082 kg 15,000 lbs / 6,804 kg
Minimum arm reach 41.8" / 1,062 mm 39.4" / 1,003 mm
Maximum arm reach 56.1" / 1,426 mm 63.7" / 1,618 mm
Maximum operating
hydraulic pressure
5,020 PSI 6,000 PSI
Shipping weight 305 lbs / 139 kg 570 lbs / 259 kg
Model
RBJ18000 RBJ25000
Lifting capacity 18,000 lbs / 8,165 kg 25,000 lbs / 11,340 kg
Minimum arm reach 39.6" / 1,008 mm 39.6" / 1,008 mm
Maximum arm reach 63.4" / 1,612 mm 63.4" / 1,612 mm
Maximum operating
hydraulic pressure
7,200 PSI 8,050 PSI
Shipping weight 788 lbs / 358 kg 802 lbs / 363 kg
Specifications are subject to change without notice.
About Vehicle Wheelbases
A BendPak four-post Lift supports less weight than its rated capacity when the wheelbase of the
vehicle on the Lift is shorter. This is because the wheels of these shorter wheelbase vehicles are closer
to the middle of the Runways, where there is less strength. Consequently, the rated capacity of that
Lift is less for these shorter wheelbase vehicles.
For example, if you want to raise a vehicle with a wheelbase of 100" on an HDS-14LSX Lift, the rated
capacity of the Lift is reduced by 50% to 7,000 lbs (3,175 kg).
Rated capacity information is included in the Specifications section in the manual of all four-post Lifts.
Refer to the manual for information for a specific Lift.
