Benelli TORNADO NAKED TRE R160 User Manual

OPERATION
36
4 • OPERATION
4.4 Selecting the display function
ATTENTION
The display modification or regulationoperations, must be made 3 seconds after the motor starting.
The display is provided with 3 main functions:
1) “TOTAL”/“TRIP”
2) “CHRONO“/”LAP”
3) “CLOCK“/”TRIP”
To move from the visualisation 1 “Total”/”Trip” to the button for more than 2 seconds.
To move from the visualisation 2 “Chrono”/”Lap” to the visualisation 3 press the“Start” button for more than two seconds (when the
chronometer is switched off).
To switch from function 3 to function 1, keep pressed the“Start” button for less than two seconds.
(Start>2sec)
(Start>2sec with chronometer o)
(Start<2sec)

Benelli TORNADO NAKED TRE R160 Specifications

General

Gearbox	6-speed
Final Drive	Chain
Compression Ratio	12.5:1
Starting System	Electric
Clutch	Wet multi-plate
Front Tire	120/70-ZR17
Rear Tire	190/50-ZR17
Max Power	157.8 hp @ 10, 200 rpm
Max Torque	120 Nm @ 8, 400 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork
Front Brake	2 x 320 mm floating discs, Brembo radial calipers
Rear Brake	Single disc, 220 mm
Weight	205 kg (452 lbs)
Bore x Stroke	88 mm x 62 mm
Frame Type	Steel trellis
Length x Width x Height	790 mm
Wheelbase	1443 mm
