Benelli TORNADO NAKED TRE R160 User Manual

OPERATION
44
4 • OPERATION
4.10 Starting the engine
As you turn the ignition switch to the ON position, the instruments and the warning lights will go through the self-diagnostic
cycle; during this phase, make sure that all the warning lights on the dashboard come on. One of the following conditions must be
verified, in order thatthe ignition switch system allows engine starting:
The gears are in neutral.
The gears are engaged, the clutch lever is pulled and the side stand is up.
Press the start button without turning the throttle twist grip.
As soon as the engine starts, release the button.
• Do not press the start button for longer than 5 consecutive seconds.
• Avoid warming up the engine while thevehicle is stationary. It is advisable to bring the engine to the
working temperature by riding at reduced speed.
• To ensure the maximum life of the engine, never speed up at full throttle when the engine is cold.

Benelli TORNADO NAKED TRE R160 Specifications

General

Gearbox	6-speed
Final Drive	Chain
Compression Ratio	12.5:1
Starting System	Electric
Clutch	Wet multi-plate
Front Tire	120/70-ZR17
Rear Tire	190/50-ZR17
Max Power	157.8 hp @ 10, 200 rpm
Max Torque	120 Nm @ 8, 400 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork
Front Brake	2 x 320 mm floating discs, Brembo radial calipers
Rear Brake	Single disc, 220 mm
Weight	205 kg (452 lbs)
Bore x Stroke	88 mm x 62 mm
Frame Type	Steel trellis
Length x Width x Height	790 mm
Wheelbase	1443 mm
