Benelli TORNADO NAKED TRE R160 User Manual

OPERATION
39
4 • OPERATION
Set “Service”
When the first 1000 Km (600Mi) will be reached and every 5000Km (3100Mi) you will see the flashing Service pilot light on the display,
instead of the partial “Trip”rip” for 10 seconds during the vehicle starting.
To reset the Service pilot light, press the START button for at least ten seconds until the pilot light is switched off.
4.5 Adjusting the clock
Switch to function 3
Press the “Start” button (> 2 sec.); the first figure will start flashing.
Repeatedly press the “Start” button until the desired figure has been entered.
Press the “Start” button (> 2 sec.) to enter the following figure.
Repeat the above procedure to enter the second figure of the “hours”, the first and second figure of the “minutes”.
Press the “Start” button (> 2 sec.) to confirm the time adjustment and to stop the selection (the flashing).

Benelli TORNADO NAKED TRE R160 Specifications

General

Gearbox	6-speed
Final Drive	Chain
Compression Ratio	12.5:1
Starting System	Electric
Clutch	Wet multi-plate
Front Tire	120/70-ZR17
Rear Tire	190/50-ZR17
Max Power	157.8 hp @ 10, 200 rpm
Max Torque	120 Nm @ 8, 400 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork
Front Brake	2 x 320 mm floating discs, Brembo radial calipers
Rear Brake	Single disc, 220 mm
Weight	205 kg (452 lbs)
Bore x Stroke	88 mm x 62 mm
Frame Type	Steel trellis
Length x Width x Height	790 mm
Wheelbase	1443 mm
