Diagram of the unit
1.LCD display.
2. :Time set button.
3 :.Backlight button
4.Test button.
5.Function switch.
6. :Time choose button.
7.Red high voltage test wire socket.
8.Green protect test wire socket.
9.Black test wire socket.
10.DC input interface (12V/1A)
11.Black test wire and alligator clip.
12.Green protective test wire and alligator clip.
13.Red Hi- volt test wire.
Caution
The data in the diagram of the unit is a simple instruction.
Read the operation to get a detail operation guidance.
