10
With Dip-Switch ON:
- the optical sensor is disabled
- braking is not carried out
- it is recommended to reduce the movement speed by switching DIP3 to ON
Diagnostic LED’s
The control unit has a series of LED’s to provide diagnostic information on the status of all the functions:
POWER LED Blinks to signal the unit is powered
STOP LED OFF when the STOP button is pressed
PHOT LED OFF when the photocells are not aligned or obstructed
OPN LED ON when the OPEN button is pressed
CLS LED ON when the CLOSE button is pressed
PP LED ON when the PP (Step-by-step) button is pressed
PED LED ON when the PEDESTRIAN button is pressed
SWO LED OFF when the SWO open travel limit switch trips
SWC LED OFF when the SWC close travel limit switch trips
Before any action the control unit runs a check-up on its correct operation. If any error is found the motor
is stopped and the Power LED blinks rapidly to signal there is a fault.
Conguration with built-in receiver (only “RI” versions)
The control unit is tted with a built-in radio module for receiving remote controls both with xed codes
and variable codes (see dip-switch 8 functions), with a frequency of 433.92MHz.
For a transmitter to be used, the module rst has to self-learn its code. The memorise procedure is
illustrated below, the module can memorise up to 64 different codes.
Memorising a new transmitter by activating the P.P. function
- Press the PGM button once for 1sec and the Power LED will start blinking at 1 sec intervals.
- Press the transmitter button within 10 sec to memorise with the P.P. (Step-by-step) function
To exit the programming procedure wait 10 sec or press the PGM button for 1 sec, the Power LED will
return to normal blinking at 3 sec intervals.
Memorization of a new transmitter with activation of 2nd radio channel output
- Press button PGM twice, each time for at least 2 seconds, the Power LED switches on with xed
light.
- Within 10s, press the transmitter push-button which should be stored in memory with 2nd radio
channel function.
To exit the programming mode, wait for 10s or press the PGM button for 2 seconds, the Power LED
ashes regularly again.
Cancelling all transmitters from the memory
- Keep the PGM button pressed for 15 sec, the Power LED will start blinking rapidly and when it goes out
the memory has been erased.
- Release the PGM button, the memory has been cancelled and the Power LED will return to normal
blinking at 3 sec intervals.
N.B.:
The transmitters are stored on an EPROM (U6) memory board that can be removed and installed in a new
control unit in case of breakdown.
For safety reasons, transmitters cannot be memorised during the open/close cycles of the motor.
When entering the memorise transmitter procedure, if the Power LED gives a prolonged blink and then
goes out, this signals that the receiver memory is full and no other transmitters can be memorised or that
the transmitter is not compatible.
