Beninca KER - Diagram

3
DL1
DL2
N
G N D L
LAMP 115/230Vac
40W max
COM
M
C
24Vac
200mA max
P.P. STOP SWO SWC PHOT COM
P1 P2
SW
1 6
TW TCA
1918
ANT
SHIELD
ANT
U2
F3
F2
Lock
12Vac
L
N
L O C K
D I P 5 : O F F
F3 KER230: F6,3A
F3 KER115: F10A
F2: F315 mA
