Page #13 background image
13
28-29 DAS
Input, safety edge contact.
Resistive edge: closed “ DAS” jumper.
Mechanical edge: open “DAS” jumper.
When the safety edge is activated, the gate movement stops. The gate movement is re-
versed for approximately 3 sec if the INVA logic is ON. If no safety edge is used: “DAS”
Jumper open, jumper between terminals 28-29.
30-31 Aerial
Connection of the antenna to the receiver extractable board (30-signal/31-screen).
32-33 2
nd
radio channel Output, 2
nd
radio channel of the two-channel extractable receiver.
34-35 SAFETY
Emergency stop connection. WARNING: Mains power supply.
Remove the jumper and connect a N.C., changeover switch, suited for the mains voltage.
See wire diagram.
36-37-38
Selection of
Mains power
supply
Selection of power supply voltage, short-circuit:
36 and 37 for three-phase power supply (400Vac)
37 and 38 for single-phase power supply (230Vac)
39-40
Single-phase
power supply
Input, single-phase mains power supply 230Vac/50Hz (39-L / 40-N)
39-40-41
Three-phase
power supply
Input, or three-phase mains power supply, 400Vac/50Hz (39-R / 40-S / 41-T).
Programming
The various functions of the control unit can be programmed by using the LCD display provided on the side of the unit and by set-
ting the desired values on the Programming Menu, as described hereunder.
The Parameters Menu allows for the presetting of a digit value to a function, like an adjustment trimmer.
The Logic Menu allows for the activation and deactivation of a function, like the setting of a Dip-Switch.
The special functions follow the Parameters Menu and the Logic Menu and can vary according to the type of control unit or soft-
ware review.
To access programming :
1 – Press the <PG> push-button, the first Parameters Menu “PAR” appears on the display.
2 – Select the desired menu by using the <+> or <-> keys (PAR>>LOG>>NMAN>>RES>>PAR>>....).
3 – Press the <PG> push-button, the display shows the first function available in the Menu.
4 – By using the <+> or <-> keys select the function to be modified.
5 – Press the <PG> push-button, the currently preset value for the selected function is displayed.
6 – By using the <+> or <-> keys, select the value which is to be assigned to the function.
7 – Press the <PG> push-button and the “PRG” message is displayed. This means that programming has been completed.
Note:
The <+> e <-> push-buttons, when the unit is not in programming mode, perform the OPEN and CLOSE function, respectively, in
service man mode (the buttons should be kept pressed for the entire duration of the operation).
When upon a Function Menu, press keys <+> e <-> simultaneously to pass to higher menu without making any change.
When the unit is switched on, the Software version is displayed for around 2sec.
Keep either keys <+> or <-> pressed to speed up the increase/decrease of values.
After 60 sec wait, the control unit exits the Programming mode and the display switches off.
Parameters, Logic and Special Functions
In the tables hereunder the single functions available in the control unit are shown.
PARAMETERS (PAR)
MENU FUNCTION
MIN-MAX-
(Default)
MEMO
TCA
Automatic closure time. Active with logic “TCA”= ON only.
At the end of the preset time, the control unit sends a closure control signal.
1-240-(40s)
TM
Motor operating time. The operation time is adjusted during the opening and closing
phases of the motor.
5-240-(40s)
Tped
The stroke time of the gate leaf is adjusted during the partial opening phase (pedes-
trian mode).
5-180-(10s)
SnSo
* The amperometric sensor sensitivity is adjusted in the opening phase. This is oper-
ating only with logic AMP:ON.
1:maximum sensitivity - 99:minimum sensitivity.
The sensor triggering in the opening phase stops the movement immediately.
1-99-(20%)
SnSC
* The amperometric sensor sensitivity is adjusted in the closing phase. This is operat-
ing only with logic AMP:ON.
1: maximum sensitivity - 99:minimum sensitivity.
When the sensors triggers in the closing phase, the gate stops immediately and a
reversion movement (opening) starts for approximately 3 sec.
1-99-(20%)
