14
TLS
The activation time of the courtesy light is adjusted. The contact closes with the be-
ginning of the opening operation. The time counting starts only with gate completely
closed.
1-240-(1s)
SaFM
This is operating only with logic SMOT:ON. The motor protection switch triggering is
adjusted. The value is expressed in Amperes.
1: triggering of protection switch at 1 Ampere of consumption
14: protection disabled.
1-14-(6A)
* WARNING:
An incorrect setting of these parameters may cause danger. Please comply with regulations in force!
LOGIC (LOGI)
MENU FUNCTION
ON-OFF-(Default)
MEMO
TCA
The automatic closure is enabled or disabled.
Off: disabled automatic closure.
On: enabled automatic closure.
(ON)
IbL
The multi-flat function is enabled or disabled.
Off: disabled multi-flat function.
On: enabled multi-flat function. The P.P. (Step-by-step) impulse or the impulse of the
transmitter has no effect in the opening phase.
(OFF)
SCL
The rapid closure is enabled or disabled.
On: enabled rapid closure. With open gate or gate in the opening phase, the activation
of the photocell causes the automatic closure of the gate 3 sec after its activation. This
function is enabled only with TCA:ON
Off: rapid closure disabled.
(OFF)
PP
The operating mode The operating mode of the “P.P.” (Step-by Step) button and of the
transmitter is selected.
Off: Operation: OPEN > STOP > CLOSE > STOP >
On: Operation : OPEN > CLOSE > OPEN >
(OFF)
PRE
Forewarning flashing light enabled or disabled.
Off: disabled forewarning flashing light.
On: enabled forewarning flashing light. The flashing light is activated 3 sec before the
motor starts.
(OFF)
CLOC
The OPEN input mode is selected.
Off: OPEN input, with OPEN function.
On: OPEN input, with CLOCK function.
To be used for connection to timer for timed opening/closing. (CLOSED contact: open
gate. OPEN contact: normal operation).
(OFF)
htr
The Service Man function is enabled or disabled.
Off: Automatic operation.
On: Service Man operation.
The OPEN/CLOSE push-buttons should be kept pressed for the entire operating time.
(OFF)
BLC
The lock function is enabled or disabled.
Off: Lock function disabled.
On: Lock function enabled. After the triggering of the closure limit switches, the control
unit delays the stop by approx. 0.5sec in order to allow a better resting of the gate leaf
onto the stoppers. DAS input is activated in the closing phase only.
Note: In case of sliding gates, leave to OFF.
(OFF)
Pho1
Photocell 1 input in the opening phase is enabled or disabled.
On: Photocell 1 is activated in the closing phase only.
Off: Photocell 1 is activated in both opening and closing phases.
(OFF)
Pho2
Photocell 2 input in the opening phase is enabled or disabled.
On: Photocell 2 is activated in the closing phase only.
Off: Photocell 2 is activated in both opening and closing phases.
(OFF)
Pho3
Photocell 3 input in the opening phase is enabled or disabled.
On: Photocell 3 is activated in the closing phase only.
Off: Photocell 3 is activated in both opening and closing phases.
(OFF)
Pho4
Photocell 4 input in the opening phase is enabled or disabled.
On: Photocell 4 is activated in the closing phase only.
Off: Photocell 4 is activated in both opening and closing phases.
(OFF)
TSTP
The operating mode of output SCA/TESTPHOT is selected.
On: Photocell power supply in Test mode as per diagram at page 4. Before each
operation all PHOT inputs are checked. If the result is negative, the operation will not
take place.
Off: Output preset as open gate warning LED.
(OFF)
