11/ 2018 BENNING IT 105
19

- Connect the red measuring lead/jack L
5
to the external conductor L.
- Connect the black measuring lead/jack N
7
to the neutral conductor N.
- Connect the green measuring lead/jack PE
6
to earth PE.
In case of an incorrect mains voltage, measurement will be blocked.
M Warning symbols. “Warning of electrical danger!”, “Attention! Please observe documentation!” and
“Tester is overheated!”; please observe the relevant sections of this operating manual.
N Symbol indicating a defective fuse
5. General information
The BENNING IT 105 is intended for electrical safety tests in compliance with DIN VDE 0100-600
(IEC 60364-6) and DIN VDE 0105-100 (EN 50110).
- Appliance dimensions: (length x width x height) = 235 x 132 x 92 mm
- Appliance weight: 1370 g incl. batteries
6. Ambient conditions
- The BENNING IT 105 is intended for making measurements in dry environment,
- Maximum barometric elevation for making measurements: 2000 m,
- Overvoltage category/ setting category: IEC 61010-1 → 300 V category III,
- Contamination class: 2,
- Protection class: IP 40 (DIN VDE 0470-1 IEC/ EN 60529)
IP 40 means: Protection against access to dangerous parts and protection against solid impurities of
a diameter > 1 mm, (4 - first index). No protection against water, (0 - second index).
- EMC: EN 61326-1
- Ambient temperature and relative humidity:
For ambient temperatures from 0 °C to 40 °C: non-condensing
- Storage temperature: The BENNING IT 105 can be stored at any temperature within the range of
- 25 °C to + 65 °C (relative humidity from 0 to 90 %). The batteries should be removed from the instru-
ment for storage.
7. Electrical specifications
Note: The measuring accuracy is specified as the sum of
- a relative fraction of the measured value and
- a number of digits (counting steps of the least significant digit).
The specified measuring accuracy is valid for temperatures within the range of 18 °C to 28 °C and for a
relative humidity lower than 80 %.
7.1 Voltage (V) frequency (Hz)
Measuring range Resolution Accuracy
0 V - 440 V AC/DC 1 V ± (5 % + 2 digits)
45 Hz - 65 Hz 1 Hz ± 1 Hz
7.2 Continuity test (RLOW)
Measuring range Resolution Accuracy
0.15 Ω - 199 Ω max. 0.01 Ω ± (2 % + 5 digits)
Measuring current: > 200 mA
Open-circuit voltage: > 4 V, < 8 VDC
Number of periodic testing (DIN EN 61557-4): approx. 4000
7.3 Insulating resistance measuring (RISO)
Measuring range Resolution Accuracy
0.20 MΩ - 199 MΩ max. 0.01 MΩ ± (5 % + 5 digits)
Test voltage: 250 VDC/ 500 VDC/ 1000 VDC, - 0 % + 20 %
Test current: > 1 mA, < 2 mA in case of a short-circuit
Number of periodic testing (DIN EN 61557-2): approx. 3000
Test voltage indication: ± 5 %
