BenQ G2200W Service Manual

22” LCD Color Monitor BenQ G2200W
2
1. About This Manual
This Service Manual is issued by engineer of TPV customer service according to the structure and capability
of various models. The purpose of Service Manual is to provide a guide line to engineers to repair different
models. The appearance and capability is introduced in this Service Manual. It is better for repair engineer to
have a rough idea of this model through reading the Service Manual. Please do pay attention to the item part of
THE DISASSEMBLY when repair the machine and also do the protection of Panel any time. When repairing the
circuit board, please follow the requirement of RoHS and refer to the circuit diagram and repairing process that
attached in the Service Manual. The method of firmware updated, the way of using the menu and some
information that may be used when repairing are also attached in the Service Manual that provide repair
engineer various choice.
If you have any questions, please contact with the engineers of TPV customer service.
COLOR MONITOR
MODEL ID G2200W (China)
1st Edition
Feb. 2008

BenQ G2200W Specifications

General

Display diagonal	22 \
Separate H/V sync	No
Display resolution	1680 x 1050 pixels
Contrast ratio (dynamic)	2500:1
Contrast ratio (typical)	1000:1
Digital vertical frequency	55 - 76 Hz
Digital horizontal frequency	31 - 83 kHz
Display brightness (typical)	300 cd/m²
Video in	DVI-D, D-Sub
Ethernet LAN (RJ-45) ports	0
HDCP	Yes
Certification	TCO'03
Product color	Black
Market positioning	-
Bundled software	Driver CD
Power consumption (typical)	45 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
LED indicators	Stand-by

Weight and Dimensions

Depth (with stand)	163.4 mm
Width (with stand)	401.6 mm
Height (with stand)	512.2 mm
Weight (without stand)	5300 g
