BenQ G2200W Service Manual

22” LCD Color Monitor BenQ G2200W
41
6.4 BOM List
TC8MRJDYMWBGHN
Location TPV Part No. Description
019G6014 1 TIE FOR STRIP
040G 581 26704 SHIPPING LABEL
040G 581881 4A WARRANTY LABEL
041G 68508 A CONTROL CARD
044G6002689 1A PAPER BOARD
044G9003214 CORNER PAPER
045G 77 3 PE PACKING
050G 600 1 W WHITE STRAP
050G 600 2 HANDLE1
050G 600 3 HANDLE2
052G 1150 C INSULATING TAPE
052G 1186 SMALL TAPE
052G 1207 A ALUMINIUM TAPE
052G6019 1 INSULATING TAPE
E08902 089G 728HAA 2D SIGNAL CABLE
089G179E30NA03 FFC CABLE
E08901 089G414A18N YH POWER CORD(32E1818021)
0M1G 130 5 47 CR3 SCREW
0M1G 130 5120 SCREW
0M1G1730 6120 SCREW,42-D020523
0M1G1730 6120 SCREW,42-D020523
705GQ834049 22" LCD BEZEL ASS'Y
A33G0248ADP 1L0100 KEY PAD 1
A33G0248ADP 2L0100 KEY PAD 2
A33G0249BAAA1C0100 POWER BUTTON
A33G0250ADQ 1C0100 LENS
A34G0639ADPA1B0130 BEZEL(L22W-7BENQ)
705GQ834050 22" LCD REAR COVER ASS'Y
A33G0258ADPC1L0100 LOGO COVER
A34G0640ADP 1B0130 REAR COVER22"
705GQ834051 22" LCD STAND BASE ASS'Y
0M1G1740 10120 SCREW 42A9940008
0Q1G1840 10120 SCREW
A33G0251ADP 1L0100 CABLE CLIP
A33G0335ADP 1L0118 STAND-FRONT
A34G0642ADP 1B0100 STAND-BACK

BenQ G2200W Specifications

General

Display diagonal	22 \
Separate H/V sync	No
Display resolution	1680 x 1050 pixels
Contrast ratio (dynamic)	2500:1
Contrast ratio (typical)	1000:1
Digital vertical frequency	55 - 76 Hz
Digital horizontal frequency	31 - 83 kHz
Display brightness (typical)	300 cd/m²
Video in	DVI-D, D-Sub
Ethernet LAN (RJ-45) ports	0
HDCP	Yes
Certification	TCO'03
Product color	Black
Market positioning	-
Bundled software	Driver CD
Power consumption (typical)	45 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
LED indicators	Stand-by

Weight and Dimensions

Depth (with stand)	163.4 mm
Width (with stand)	401.6 mm
Height (with stand)	512.2 mm
Weight (without stand)	5300 g
