Projection dimensions
Installation for a 16:9 ratio screen
The screen aspect ratio is 16:9 and the projected picture is in 16:9 aspect ratio
H
W
Projection distance
Center of lens
Screen
16:9 Screen diagonal
Vertical offset
To optimize your projection quality, we suggest doing the projection by following
the values in the non-gray cells. The values in the gray cells are for reference only.
All measurements are approximate and may vary from the actual sizes.
If you want a permanent installation of the projector, we recommend that you
use the actual projector to physically test the projection size, distance, and the
projector's optical characteristics prior to the installation. This helps you
determine the exact mounting position which best suits your installation.
If your screen size is not in the table above, please contact your dealer for
assistance.
Screen size Distance from screen (mm)
Vertical offset
(Lowest/Highest
lens position) (mm)
Diagonal
H (mm) W (mm)
Min length
Average
Max length
Inch mm (max. zoom) (min. zoom)
30
40
50
60
80
95
100
110
120
130
140
150
160
170
180
190
200
250
300
762
1016
1270
1524
2032
2413
2540
2794
3048
3302
3556
3810
4064
4318
4572
4826
5080
6350
7620
664
886
1107
1328
1771
2103
2214
2435
2657
2878
3099
3321
3542
3763
3985
4206
4428
5535
6641
374
498
623
747
996
1183
1245
1370
1494
1619
1743
1868
1992
2117
2241
2366
2491
3113
3736
744
999
1253
1508
2017
2399
2526
2781
3035
3290
3545
3799
4054
4308
4563
4817
5072
6345
7618
860
1154
1447
1740
2327
2767
2914
3207
3500
3794
4087
4380
4674
4967
5260
5554
5847
7314
8780
977
1309
1641
1973
2637
3135
3301
3633
3965
4297
4629
4961
5293
5626
5958
6290
6622
8282
9942
37
50
62
75
100
118
125
137
149
162
174
187
199
212
224
237
249
311
374
