10
Signal Timing:
Mode
Resolution
Plus
Frequency
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel
Frequency
(MHz)
IBM, VGA 720x400@70Hz 31.469 70.080 28.320
VGA
640x480@60 Hz 31.469 59.940 25.175
640x480@72 Hz 37.861 72.809 31.500
640x480@75 Hz 37.500 75.000 31.500
SVGA
800x600@56Hz 35.156 56.250 36.000
800x600@60Hz 37.879 60.317 40.000
800x600@72Hz 48.077 72.188 50.000
800x600@75Hz 46.875 75.000 49.500
XGA
1024x768@60Hz 48.363 60.004 65.000
1024x768@70Hz 56.476 70.069 75.000
1024x768@75Hz 60.023 75.029 78.750
XGA+ 1152x864@75Hz 67.500 75.000 108.000
WXGA+ 1280x960@60Hz 60.000 60.000 108.000
SXGA
1280x1024@60Hz 63.981 60.020 108.000
1280x1024@75Hz 79.976 75.025 135.000
WXGA 1360x768@60Hz 47.712 60.015 85.500
WXGA+ 1440x900@60Hz 55.935 59.887 106.500
WSXGA+ 1680x1050@60Hz 65.290 59.954 146.250
WUXGA 1920x1080@60Hz(R) 66.590 59.930 138.500
WUXGA 1920x1080@60Hz 67.500 60.000 148.500
MAC 640x480@67Hz 35.000 66.667 30.240
MAC 832x624@75Hz 49.725 74.550 57.283
MAC 1152x870@75Hz 68.681 75.062 100.000
Remark: To make sure the good compatibility, the timings listed in above table is not always same as
in EDID.
2. Component Video Signal:
Connector Pin definition:
(1) Component video pin define:
A B C
(A) Cr/Pr Input
(B) Cb/Pb Input
(C) Y Input for YCrCb or YPrPb.
