(2) Component audio pin define:
A B
(A) Audio Input, right channel, for YCrCb or YprPb
(B) Audio Input, left channel, for YCrCb or YPrPb
Signal Level:
(1) YPbPr input:
Component signal: 0.7~1Vp-p/75 Ohm, negative
(2) Audio:
Level: 500 mVrms
Impedance: 600 ohms
Signal support timing:
Input from YcbCr:
Lines per frame Horizontal frequency(kHz)
V
ertical frequency(Hz) System
525 15.734 60 NTSC
625 15.625 50 PAL(B,G ,D,K,I)
625 15.625 50 SECAM
525 15.734 60 4.43NTSC
Input from YpbPr:
Horizontal frequency (kHz) Vertical frequency (Hz) Signal
15.735 60 SDTV 480i
31.47 60 SDTV 480p
45.00 60 HDTV 720p
33.75 60 HDTV 1080i
67.50 60 HDTV 1080p
3. Audio input level
Audio monitor output Signal:
Source Input Input level ( mVrms) Audio Out
PC 500 PC
HDMI 500 (DVI)HDMI
TV 500 TV
YPbPr 500 YPbPr
AV 500 AV
SV 500 SV
