20
(5) Audio Spec
Parameter Specification
Base band Input
Power Output Max Rating
5W at 10% T.H.D Distortion
Speaker Impedance
main spk :8 Ω
Line In
500 mV rms (Typ)
1.6 V rms (Max)
Impedance: 600 ohms
Line Out
500 mVrms +/- 10%
@1K Hz tone (with +/-25k Hz deviation at input, volume
with non-attenuation and loading with 47k Ohm)
Flatness of Amplitude Response +/-
3 db (at 1KHz @1W)
Total Harmonic Distortion
(Po=0.1 to 1 W, f=1KHz)
<2%
Signal to Noise:
40 db (50Hz to 15 KHz)
(6) Key pad control
(1) Power key: This switch is located on the Front bottom side of the display. It is a soft power
switch and not a main disconnection device. Main disconnection shall be accomplished by
physically removing the power cord from the display.
(2) Menu: Located on the top side of the display. Key shall enter, exit the OSD.
(3) CH+/CH- : Located on the top side of the display. Change Channels or navigate through OSD
depending on mode.
(4) VOL+/VOL-: Located on the top side of the display. Change Volume or navigate through OSD
depending on mode.
(5) Input:
External Connector
AC-In
RGB Input
HDMI Input
Audio Inputs X2
Audio Inputs for PC Audio
Audio Output
RF input
Composite Video
Component Video
S-Video
