BenQ MP512 - Page 13

13
z Video Input
z S-Video input
Pin Description
1 GND
2
GND
3 Luminance
4 Chroma
z Control Port
Pin Definition
1 Composite video
input
Pin Description Pin Description
1 NC 2 R
X
3 T
X
4 NC
5 GND 6 NC
7 RTSZ 8 CTSZ
9 NC
2
4
1
3
Composite input
1
