5. Assembly FM Module:
5.1 Place FM on “HLD FM” surface(Fig. 5-1) and use “Clip FM” to fix FM(Fig. 5-2).
Fig. 5-1 Fig. 5-2
Pre assemble this screw
not over the side surface.
Pre assemble this screw not
over the bottom surface.
Touch the
side surface
Clip FM hook
the punch points
