IR Lens assemble direction
6 Ballast assemble & wire alignment concern
1) Ballast screw quantity *2Î step1 : top-left; step2: bottom-right
2) Wire ballast to M/B alignment , (note 2)
3) Wire ballast to PWR/B alignment , (note 3)
4)
Wire ballast to Lamp alignment , (note 4 )
SCREW*2
Note 4
Note 3
Note 2
