77
11. Main BD Shielding Assemble and Wire alignment
11-1 Screw Assemble for MB shielding
11-2 Screw Assemble for MB shielding
12 Engine and Lower case constrain concern
Screw Type: 8F.VA564.7R0
11-1
CW wire alignment
First Fixed location
3rd Fixed location
Second Fixed location
