Chapter 4 - LED Messages Definition
Power Te m p Lamp
Status Note
Stand-by
Powering up
Normal operation
Normal power-down cooling
Lamp Error Messages
Lamp error in normal operation(single lamp)
Scaler reset fail
CW start fail
Thermal Error Messages
Fan 1 error (the actual fan speed is ±20% outside the
desired speed.)
Lamp Fan
Fan 2 error (the actual fan speed is ±20% outside the
desired speed.)
Ballast Fan
Fan 3 error (the actual fan speed is ±20% outside the
desired speed.)
Blower Fan
Thermal Sensor 1 open error (the remote diode has an
open-circuit condition.)
DMD
sensor
Thermal Sensor 2 open error (the remote diode has an
open-circuit condition.)
Thermal Sensor 1 short error (the remote diode has an
short-circuit condition.)
Thermal Sensor 2 short error (the remote diode has an
short-circuit condition.)
Temperature 1 error (over limited temperature)
Temperature 2 error (over limited temperature)
Fan IC #1 I2C Connection error
O
G
G
O
R
R R
G R
R
R R
R G
R
R R
R R G
G R R
G R G
O R R
O R G
G R
