BenQ MS506 - User Manual

MS506/MS3081+/MS504A
Digital Projector
User Manual

Summary

Important Safety Instructions

General Safety Guidelines

Essential safety guidelines for operating the projector, including reading the manual and avoiding direct eye exposure to the lens.

Ceiling Mount Safety

Specific safety recommendations and requirements for mounting the projector on a ceiling.

Introduction and Projector Features

Projector Features Overview

Details the key features and technologies offered by the BenQ projector.

Shipping Contents and Accessories

Lists standard and optional accessories included with the projector.

Projector Exterior View and Connectivity

Front and Upper Side View

Identifies external components on the front and upper surfaces of the projector.

Rear and Lower Side View

Details the rear and lower side connectors and mounting points of the projector.

Projector Controls and Operation

Projector Top Panel Controls

Explains the functions of buttons and indicators on the projector's top panel.

Remote Control Operation

Remote Control Button Layout

Details the buttons and their functions on the projector's remote control.

Remote Control Usage and Maintenance

Remote Control Effective Range

Specifies the optimal distance and angle for using the remote control effectively.

Replacing Remote Control Batteries

Provides instructions on how to replace the batteries in the projector's remote control.

Projector Positioning and Installation

Choosing an Installation Location

Describes four recommended installation positions for the projector (Front Table, Rear Ceiling, etc.).

Projected Image Size and Dimensions

Projection Dimensions and Charts

Provides a table with screen sizes, projection distances, and vertical offsets for optimal image sizing.

Connecting the Projector to Sources

General Connection Guidelines

Outlines steps for connecting various A/V devices and computers to the projector.

Video and Audio Connection Guide

Connecting Video Sources

Explains how to connect different video sources like Component, S-Video, and Video.

Connecting Audio

Describes the projector's audio capabilities and how to connect audio sources.

Projector Startup and Initial Setup

Powering On the Projector

Step-by-step guide on how to connect power and start the projector.

Initial Setup and Language Selection

Covers initial language selection and password prompts upon first startup.

Image Adjustment and Fine-Tuning

Adjusting Projection Angle

Instructions on using the adjuster foot to set the projector's angle and height.

Auto-Image Adjustment

How to use the AUTO function for automatic picture quality optimization.

Fine-Tuning Image Size and Clarity

Details on using the zoom and focus rings for precise image adjustment.

Correcting Image Distortion (Keystoning)

Correcting Keystone Distortion

Explains how to correct trapezoidal image distortion using projector controls or OSD menu.

OSD Menu Navigation and Settings

OSD Menu Overview

Provides an overview of the main menu, sub-menus, and options available in the OSD.

Setting the OSD Language

Step-by-step guide to selecting the desired language for the On-Screen Display.

Projector Security: Locks and Passwords

Using a Security Cable Lock

Instructions on how to attach a security cable lock to prevent theft.

Setting Up the Password Function

Guide to enabling and setting a password for projector access control.

Password Management and Recall

Password Recall Procedure

Steps to follow if the projector password is forgotten.

Changing or Disabling Password

Instructions for changing an existing password or disabling the password protection feature.

Switching Input Sources

Selecting the Video Source

How to switch between different connected input sources for display.

Image Magnification and Aspect Ratio

Magnifying and Panning the Image

Using digital zoom and arrow keys to magnify and navigate the projected image.

Selecting Aspect Ratio

How to change the image aspect ratio (e.g., 4:3, 16:9) to match source or display needs.

Optimizing Image Quality

Using Wall Color Adjustment

How to adjust colors when projecting onto non-white surfaces.

Selecting Picture Modes

Choosing predefined picture modes (Dynamic, Cinema, etc.) for optimal viewing.

Setting User Picture Modes

Customizing and saving user-defined picture settings.

Image Quality Fine-Tuning

Adjusting Image Parameters

Detailed adjustments for brightness, contrast, color, tint, and sharpness in user modes.

Selecting Color Temperature

Options for adjusting the overall color temperature of the projected image.

Advanced Color and 3 D Settings

Setting Preferred Color Temperature

Fine-tuning specific color temperature settings like RGB Gain/Offset.

3 D Color Management

Advanced color adjustments for 3D content display.

Settings Reset and Presentation Timer

Resetting Picture Modes

Restoring picture settings to factory defaults (current or all modes).

Setting Presentation Timer

Configuring the on-screen timer for presentations.

Remote Control Features: Paging and Freezing

Remote Paging Operations

Controlling presentation slides remotely via USB connection.

Freezing the Projected Image

How to freeze and release the displayed image using the remote control.

Advanced Operation Modes: Hiding, Locking, Altitude

Hiding the Image (ECO BLANK)

Using the ECO BLANK function to temporarily hide the screen image.

Locking Control Keys

How to disable the projector's physical control buttons to prevent accidental changes.

High Altitude Operation Mode

Using the High Altitude Mode for optimal performance in specific environments.

Audio Settings and Test Pattern

Adjusting Audio Settings

Instructions for muting, adjusting volume, and disabling the power on/off ring tone.

Using the Test Pattern

How to display a grid test pattern for image size, focus, and distortion checks.

Teaching Templates Functionality

Teaching Template Features

Describes preset patterns for teaching purposes like Letter Formation and Coordinate Chart.

Projector Shutdown Procedures

Proper Projector Shutdown Procedure

Step-by-step guide on how to safely turn off the projector.

Direct Power Off Caution

Information regarding immediate power disconnection and its implications.

Menu System Navigation

OSD Menu Structure Overview

Displays the main menu, sub-menus, and options for projector settings.

System Setup: Basic Menu Details

Presentation Timer and Language Settings

Configuration options for the presentation timer and OSD language.

Operation Settings

Managing auto power off, quick cooling, instant restart, blank timer, and sleep timer.

System Setup: Advanced & Information Menus

Advanced System Settings

Covers advanced settings like High Altitude Mode, Audio, Lamp, Security, and Test Pattern.

Information Menu Options

Displays current system status information such as source, picture mode, and lamp usage.

Display Menu Functions Explained

Wall Color and Aspect Ratio Settings

Explains functions for correcting color on non-white surfaces and setting image aspect ratio.

Keystone, Position, Phase, and Size Adjustments

Details on correcting keystoning, adjusting image position, phase, and horizontal size.

Display Menu: 3 D and Teaching

3 D Functionality and Settings

How to use the 3D function, adjust 3D modes, and save/apply settings.

Using Teaching Templates

Guide for activating and using built-in teaching patterns.

Picture Menu Functions Explained

Picture Mode and Reference Mode

Selecting predefined or user-defined picture modes for optimal image quality.

Image Quality Fine-Tuning

Adjusting brightness, contrast, color, tint, sharpness, and brilliant color settings.

System Setup: Basic Menu Functions

Presentation Timer and Language Settings

Configuration options for the presentation timer and OSD language.

Operation Settings

Managing auto power off, quick cooling, instant restart, blank timer, and sleep timer.

System Setup: Basic & Advanced Functions

Basic System Settings

Panel key lock, background color, and splash screen customization.

Advanced System Settings

High altitude mode, audio, lamp, security, baud rate, and test pattern configuration.

System Setup: Advanced Features Explained

Closed Caption and Standby Settings

Enabling closed captions and configuring standby mode behavior.

Resetting All Settings

Restoring all projector settings to their factory defaults.

Information Menu: System Status Details

Current System Status Details

Displays current signal source, picture mode, lamp status, resolution, and firmware version.

Projector Maintenance and Care Guide

Cleaning the Lens and Case

Instructions for cleaning the projector's lens and exterior case.

Storing and Transporting the Projector

Guidelines for safely storing and transporting the projector.

Lamp Information and Life Extension Tips

Understanding Lamp Usage Hours

How to check the projector's total lamp usage time.

Extending Lamp Life

Tips for extending lamp life, including setting lamp modes and auto power off.

Timing Lamp Replacement

Lamp Warning Indicators

Explains the messages and indicators that signal the need to replace the projector lamp.

Projector Lamp Replacement Guide

Lamp Replacement Safety Precautions

Critical safety warnings and guidelines before replacing the projector lamp.

Initial Steps for Lamp Replacement

Procedures for opening the lamp cover and preparing for lamp removal.

Lamp Replacement Procedure

Disconnecting and Removing the Old Lamp

Detailed steps for disconnecting the lamp connector and removing the old lamp.

Installing the New Lamp

Instructions for installing the new lamp, securing it, and reconnecting the connector.

Finalizing Lamp Replacement and Timer Reset

Finalizing Lamp Replacement

Steps for closing the lamp cover, connecting power, and restarting the projector.

Resetting the Lamp Timer

How to reset the lamp timer after replacing the lamp.

Indicator Lights and Status Messages

Power, Temp, and Lamp Indicators

Explains the meaning of different light indicators for power, temperature, and lamp status.

Thermal and Lamp Events

Describes status messages related to thermal events and lamp errors.

Troubleshooting Common Projector Issues

Projector Not Turning On

Solutions for power-related issues, including no power or attempting to turn on during cooling.

No Picture or Blurred Image

Troubleshooting steps for missing pictures, focus issues, and alignment problems.

Remote Control Not Working

Common causes and solutions for a non-functional remote control.

Projector Technical Specifications

Optical and Electrical Specifications

Details on resolution, display system, lamp, power supply, and consumption.

Mechanical, Input;Output, and Environmental Specs

Information on weight, ports, control interfaces, and operating environmental conditions.

Dimensions and Ceiling Mount Installation

Projector Physical Dimensions

Provides diagrams and measurements of the projector's physical size.

Ceiling Mount Installation Guide

Details on ceiling mount screw specifications and diagrams for installation.

PC Input Timing Specifications

PC Input Resolutions and Frequencies

Table listing supported resolutions, modes, vertical, horizontal, and pixel frequencies for PC input.

Video Input Timing Specifications

Component-YPbPr Input Timing

Details supported timing for Component-YPbPr signals, including 3D compatibility.

Video and S-Video Input Timing

Lists supported timing for NTSC, PAL, SECAM, and other video signal types.

Warranty, Copyright, and Legal Information

Limited Warranty Details

Outlines the warranty terms, conditions, and limitations for the projector.

Copyright, Disclaimer, and Patents

Legal notices regarding copyright, disclaimers, trademarks, and patents.

BenQ MS506 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	23 - 120 Hz
Horizontal scan range	15 - 102 kHz
Projection technology	DLP
Contrast ratio (typical)	13000:1
Screen size compatibility	60 - 120 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-40 - 40 °
Offset	120 %
Throw ratio	1.86 - 2.04:1
Focal length range	21 - 23.1 mm
Aperture range (F-F)	2.56 - 2.8
Full HD	No
HD-Ready	Yes
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	640 x 480 (VGA), 1600 x 1200 (UXGA)
Lamp power	190 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	270 W
Power consumption (economy mode)	220 W
Placement	Desktop
Product type	Standard throw projector
Product color	Black
RMS rated power	2 W
Number of built-in speakers	1
USB connector type	Mini-USB B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	-
Noise level	33 dB
Preset modes	Cinema, Dynamic, Presentation, sRGB
Noise level (economic mode)	28 dB
On Screen Display (OSD) languages	ARA, BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DAN, DEU, ENG, ESP, FIN, FRE, GRE, HUN, IND, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR
Cables included	VGA
Remote control type	IR

Weight and Dimensions

Depth	222 mm
Width	283 mm
Height	95 mm
Weight	1800 g
