BenQ MU686 - Dimensions; Ceiling Mount Installation

Specifications 59
Dimensions
331 mm (W) x 114.4 mm (H) x 246.2 mm (D)
Ceiling mount installation
331
246.2
114.4
Unit: mm
127.7
635.92
100.57
577.7 537.9
8
199.6
77
116.99
156.37
330.98
76.540.49
Ceiling Mount screw: M4 (Max L = 25 mm; Min L = 20 mm)
Unit: mm
