Projection dimensions
MW855UST+
The screen aspect ratio is 16:10 and the projected picture is 16:10.
W
h
D
H
V
WXGA
Screen size
(Diagonal)
Screen
width (W)
Screen
height (H)
Projection
distance (D)
Offset (H)
Scale
parameter
Distance
between
Wall plate &
projection
screen (V)
inch mm inch mm inch mm inch mm inch mm mm
80 2032 67 1723 42 1077 11.40 289.0 11.80 300.0 505 274.7
85 2159 71 1831 45 1144 12.90 326.9 12.40 314.3 540 289.0
87 2210 73 1874 46 1171 13.50 341.9 12.60 320.2 555 294.9
90 2286 76 1939 47 1212 14.40 364.7 13.00 328.9 580 303.6
92 2337 77 1982 48 1239 15.00 379.7 13.20 334.4 595 309.1
95 2413 80 2046 50 1279 15.80 402.1 13.50 343.0 615 317.7
97 2464 81 2089 51 1306 16.40 417.2 13.70 348.9 630 323.6
100 2540 85 2154 53 1346 17.30 439.9 14.00 356.9 655 331.6
