Projector exterior view
1. External control panel
(See "Projector" on page 11 for
details.)
2. Lamp cover
3. Focus ring
4. Quick-release button
5. Lens cover
6. Projection lens
7. Front IR remote sensor
8. Security bar
9. Ventilation holes (intake)
10. Speaker
11. Zoom ring
12. Audio output jack
13. Audio input jack
14. Audio (L/R) input jack
15. S-Video input jack
16. RGB (PC)/Component video
(YPbPr/ YCbCr) signal input jack
17. RGB signal output jack
18. HDMI input jack
19. RS-232 control port
20. USB type A/1.5A jack
21. RJ45 LAN input jack
22. USB mini-B jack
23. Kensington anti-theft lock slot
24. Ventilation holes (exhaust)
25. Rear adjuster foot
26. Quick-release adjuster foot
27. Ceiling mount holes
28. AC power cord inlet
29. Video input jack
30. Microphone input jack
Front/upper side
1
9
5
11
3
8
7
6
4
10
2
17
16
20
12
1514
24
25
13
30
19
18
21
22
27 26
23
28
29
Rear/lower side
