Specifications
78
• The timings showing above may not be supported due to EDID file and
VGA graphic card limitations. It is possible that some timings cannot be
chosen.
Supported timing for HDMI (HDCP) input
1680 x 1050
1680 x
1050_60
59.954 65.29 146.25
ƼƼ
1920 x 1080
1920 x
1080_60
(Reduce
Blanking)
67.5 60 148.5
1920 x 1200
1920 x
1200_60
(Reduce
Blanking)
59.95 74.038 154.000
640 x 480
@67Hz
MAC13 66.667 35 30.240
832 x 624
@75Hz
MAC16 74.546 49.722 57.280
1024 x 768
@75Hz
MAC19 75.02 60.241 80.000
1152 x 870
@75Hz
MAC21 75.06 68.68 100.000
Resolution Timing
Horizontal
Frequency
(KHz)
Vertical
Frequenc
y (Hz)
Pixel
Frequency
(MHz)
3D Field
Sequent
ial
3D
top
bott
om
3D
side
by
side
640 x 480
VGA_60 59.94 31.469 25.175
ƼƼƼ
VGA_72 72.809 37.861 31.500
VGA_75 75 37.5 31.500
VGA_85 85.008 43.269 36.000
720 x 400
720 x
400_70
70.087 31.469 28.3221
800 x 600
SVGA_60 60.317 37.879 40.000
ƼƼƼ
SVGA_72 72.188 48.077 50.000
SVGA_75 75 46.875 49.500
SVGA_85 85.061 53.674 56.250
SVGA_120
(Reduce
Blanking)
119.854 77.425 83.000
Ƽ
1024 x 768
XGA_60 60.004 48.363 65.000
ƼƼƼ
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.667 94.500
XGA_120
(Reduce
Blanking)
119.989 97.551 115.5
Ƽ
1152 x 864
1152 x
864_75
75 67.5 108
1024 x 576
BenQ
Notebook
Timing
60 35.82 46.966
1024 x 600
BenQ
Notebook
Timing
64.995 41.467 51.419
1280 x 720
1280 x
720_60
60 45 74.250
ƼƼƼ
1280 x 768
1280 x
768_60
59.87 47.776 79.5
ƼƼƼ
